EP4023775A1
2022
Aitor Loizaga, Beñat Bravo, Foundry technologies, Foundry Technologies, Gorka Zarrabeitia, Iron foundry, R&D+i, Ramón Suarez, Susana Méndez, Foundry Technologies
The present invention relates to a method for preparing ductile cast iron, comprising the steps of (a) melting a base iron to obtain a molten iron; (b) treating the molten iron with a nodulazing composition; (c) introducing the nodulized molten iron into a pouring unit; (d) holding the molten iron in the pressurized pouring vessel of the pouring unit resulting in a molten iron having a sulphur content from 0.002 wt. % to 0.006 wt. %; (e) pushing the molten iron from the pressurized pouring vessel to the pouring basin of the pouring unit; (f) pouring a stream of the molten iron from the pouring basin into a mould; and (g) allowing the molten iron to solidify in said mould; wherein the molten iron is treated with an additive composition and with an inoculating composition after step d) and prior to step g); wherein the additive composition comprises a source of sulphur, a source of selenium and, optionally, a source of tellurium and/or a source of rare earth elements, and comprises a carrier; and wherein the total content of sulphur, selenium, and optionally, tellurium and/or rare earth elements, in the resulting molten iron is increased by a total amount from 0.002 to 0.012 wt.% respect to total weight of the molten iron. The present invention relates also to an additive composition for preparing ductile cast iron according to said method, and to a kit comprising said additive composition and an inoculating composition. Finally, the present invention relates to a ductile cast iron obtainable by said method and to the use of the additive composition in the production of ductile cast iron.
Aitor Loizaga, Gorka Zarrabeitia, Beñat Bravo, Susana Méndez, Ramón Suárez
Ductile cast iron, inoculants, inoculation, graphite formation, metallurgical quality.
